Description
Description
Printing Method - Serial Impact Dot Matrix Method
Print Head - Dual 9 Pin
Dot Wire Diameter - 03mm
Print Direction - Bidirectional/Unidirectional printing, Short, line-seeking printing
Graphic Resolution - Max. 240(H) x 216(V) dpi
Print Speed - Super Speed Draft : 700cps, High Speed Draft : 600cps, Draft : 450cps, Near Letter quality : 113 cps
Line Feed Pitch - 4.23mm(1/6"), 3.18mm(1/8"), n x 0.35mm(n/72"0(n=1-85), n x 0.18mm(n/144"0(n=0-255), n x 012mm(n/216)(m=0-255
Feed Speed - 5.25 inches per second
Feed Rate - 4.23mm(1/6") line feed: Approx. 47 milliseconds
Paper Route - Tractor feeder (Front), Tractor feeder(Rear), Tractor feeder(Bottom), Manual(Top), Manual(Front), Roll paper stand, Cut sheeet feeder(Rear)
Character Pitch - Super Speed Draft : 12.0 cpi
High Speed Draft : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi
Draft : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi
Near Letter Quality : 10.0 cpi, 12.0 cpi, 15.0 cpi, 17.1 cpi, 20.0 cpi, Propotional
Printing Width - 80 characters/line at ANK 10 cpi
Interface - IEEE1284-1994 Bi-directional Parallel, USB 2.0 (Full Speed), (Optional) 100BASE-TX/10BASE-T, (Optional)RS-232C (25pin)
Emulation - OKI Microline, ESC/P emulation, IBM ProPrinter emulation
Support OS - Windows 7, Windows 7 x64, Windows vista, Windows Vista x64, Windows Serever 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64
Receive Buffer - Max. 128KB
Resident Front - High Speed Draft, Draft, NLQ Courier, NLQ Gothic, OCR-B, Scalable Courier, Scalable Gothic
Front Style - Bold, Double Width, Double Height, Emphasized, Italics, Over Score, Underline
Paper Type - Continuous paper, Continuous copying paper, Cut sheet, Card, Envelope, Label
Paper Weight Adjustment - Manual
Paper Size - Continuous paper: Width 76.2-254.0mm x Length 76.2558.8mm
Single part paper: Width 99.1-256.5mm x Length 99.1-363.0mm
Multi part paper: Width 76.2-254.0mm x Length 76.2-558.8mm
Paper Weight - Continuous paper : 45-90 gsm
Single paper : 45-90 gsm
Multi part paper : 35-40gsm
Copy Capability - Normal print mode: original + 5sheets(Total Thickness<0.36mm)
High copy print mode: original + 6 sheets(Total Thickness<0.36mm)
